A Wide Variety of Motors and Drivers Details
Combinations With 2-Phase/5-Phase Stepper Motor PKP Series and CVD Series Driver
The mounting adapter for linear actuators (linear actuators) can be selected from a wide variety of products, such as the PKP series with encoder or electromagnetic brake, and can be combined.
In addition, by combining it with the CVD Series driver, low-vibration operation helps reduce resin nut wear, extend grease-up intervals, and minimize noise.
●Combination With Flat 2-Phase Stepper Motor
- Can be installed in narrow spaces (selection must be made according to load conditions)
Total Length 41.1 mm*: □42 mm mounting adapter for linear actuator + □42 mm flat 2-phase stepper motor
- *Excluding the length of lead screw
●Combination With Stepper Motor With Encoder
- Improved equipment reliability through position monitoring and detection of position errors
- Reduced encoder assembly time
Combinations With αSTEP AZ Series With Battery-Free Built-In Absolute Encoder
Combined with the AZ Series, the mounting adapter for linear actuator (linear actuator) enables high-precision return-to-home without using an external sensor.
In addition, compatible with all major industrial networks, contributing to centralized management of equipment information and reduced wiring.
- *1 AZM46 only.
- *2 Cable type for enabling one-touch connection is also available.
Combinations With Motor With Battery-Free Built-In Absolute Encoder
- Return-to-home possible even without home sensor, limit sensor
- Industrial network compatible
